Product Summary
The LAN9221I-ABZJ is a full-featured, single-chip 10/100 Ethernet controller designed for embedded applications where performance, flexibility, ease of integration and system cost control are required. The LAN9221I-ABZJ has been specifically designed to provide high performance and throughput for 16-bit applications. The LAN9221I-ABZJ is fully IEEE 802.3 10BASE-T and 802.3u 100BASE-TX compliant, and supports HP Auto-MDIX. The variable voltage I/O signals of the LAN9221I-ABZJ accommodate lower voltage I/O signalling without the need for voltage level shifters. The applications of the LAN9221I-ABZJ include Cable, satellite and IP set-top boxes, High-end audio distribution systems, Digital video recorders, DVD Recorders/Players, Digital TV, Digital media clients/servers, Home gateways, Industrial and embedded systems with extended temperature support.
Parametrics
LAN9221I-ABZJ absolute maximum ratings: (1)Supply Voltage (VDDVARIO, VDD33REG, VDD33A): 0V to +3.6V; (2)Positive voltage on signal pins, with respect to ground: +6V; (3)Negative voltage on signal pins, with respect to ground: -0.5V; (4)Positive voltage on XTAL1/CLKIN, with respect to ground: +4.6V; (5)Positive voltage on XTAL2, with respect to ground: +2.5V; (6)Ambient Operating Temperature in Still Air (TA); (7)Storage Temperature: -65℃ to +150℃; (8)Lead Temperature Range: Refer to JEDEC Spec. J-STD-020; (9) HBM ESD Performance: ±5kV.
Features
LAN9221I-ABZJ features: (1)Optimized for high performance applications; (2)Efficient architecture with low CPU overhead; (3)Easily interfaces to most 16-bit embedded CPU’s; (4)1.8V to 3.3V variable voltage I/O accommodates wide range of I/O signalling without voltage level shifters; (5)Integrated PHY with HP Auto-MDIX support; (6)Integrated checksum offload engine helps reduce CPU load; (7)Low pin count and small body size package for small form factor system designs.
