Product Summary
The EP3C80F484C6N is a Thermal Resistance.
Parametrics
EP3C80F484C6N specifications: (1)Number of Logic Blocks/Elements: 81264; (2)I/Os (Max): 295; (3)Frequency: 437.5MHz; (4)Process Technology: 65nm; (5)Operating Supply Voltage (Typ): 1.2V; (6)Logic Cells: 81264; (7)RAM Bits: 2810880; (8)Operating Supply Voltage (Min): 1.15V; (9)Operating Supply Voltage (Max): 1.25V; (10)Operating Temp Range: -40℃ to 100℃; (11)Operating Temperature Classification: Industrial; (12) Mounting: Surface Mount; (13)Pin Count: 484; (14)Package Type: FBGA.
Features
EP3C80F484C6N features: (1)Fully supports PowerPC 60x bus protocol, include PowerPC 603, 604, 740,750 and 8260.; (2)Supports up to eight PowerPC bus masters with unlimited slave device support.; (3)Supports two outstanding bus accesses.; (4)Supports address only transfer and address bus retry.; (5)Independent address bus and data bus tenure with separate bus grant and data bus grant.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 EP3C80F484C6N |
|
IC CYCLONE III FPGA 80K 484 FBGA |
Data Sheet |
|
|
||||||
