Product Summary
The TD62305F is a non-inverting transistor array, which is comprised of eight NPN darlington buffer-transistor output stages and PNP input stages.
Parametrics
TD62305F absolute maximum ratings: (1)Supply Voltage VCC: -0.5 to 7.0 V; (2)Output Sustaining Voltage, VCE (SUS): -0.5~50 V; (3)Output Current IOUT: 500mA / ch; (4)Input Voltage VIN: -0.5~7V; (5)Input Current IIN: 10mA; (6)Storage Temperature Tstg: -55~150℃.
Features
TD62305F features: (1)Output current (single output) 500mA (Max.); (2)High sustaining voltage 35 V (TD62304P/F, 62305P/F) 50 V (TD62304AP/AF, 62305AP/AF) (Min.); (3)Low level active input; (4)Input compatible with 5-V TTL and 5-V CMOS; (5)Package type-P, AP: DIP-16 pin; (6)Package type-F, AF: SOP-18 pin.
Diagrams
 |
