MX7533KN+

MX7533KN+, CMOS 4-quadrant multiplying digital-to-analog converter, DIP, 670mW, -0.3V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.65~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
101 ~ 500 :	0.80 / Piece
501 ~ 1000 :	0.65 / Piece

PartNumber:: MX7533KN+

Brand:: Maxim Integrated Products - Maxim | Pack: | D/C: 06+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Judy's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-25

From Other Seller

Part Number:MX7533KN+
US $0.65 - 1.00
Quantity:

piece

Product Summary

The MX7533KN+ is a low cost CMOS 4-quadrant multiplying digital-to-analog converter (DAC). An advanced silicon gate CMOS process combines 1- bit linearity, low power consumption, and excellent long term stability. Thin-film resistors provide 1.4% untrimmed gain error and less than 0.1% gain change with temperature over all operating ranges. The MX7533KN+ operates from a single +5V to +15V supply. The applications of the MX7533KN+ include: machine and motion control systems, automatic test equipment, μP controlled calibration circuitry, programmable gain amplifiers, digitally controlled filters, Programmable power supplies.

Parametrics

MX7533KN+ absolute maximum ratings: (1)VDD to GND: -0.3, +17V; (2)VREF to GND: ±25V; (3)RFB to GND: ±25V; (4)Digital input voltage to GND: -0.3V, VDD; (5)Output voltage(out1, out2): -0.3V, VDD; (6)Power dissipation plastic DIP(derate 8.3mW/℃ above +70℃): 670mW; ceramic, CERDIP, small outline(derate 6mW/℃ above +75℃): 450mW; (7)Storage temperature: -65℃ to +150℃; (8)Lead temperature(soldering 10 secs): +300℃.

Features

MX7533KN+ features: (1)10 bit resolution; (2)8, 9 and 10 bit end point linearity; (3)Low power consumption-20mW; (4)Four-quadrant multiplication; (5)TTL and CMOS compatible; (6)Pin-four-pin second source.
