MAX4784EUE

MAX4784EUE, quad 2:1 analog multiplexer, TSOP, -0.3V to +4.6V, ±500mA, 1176.5mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.65~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
101 ~ 500 :	0.80 / Piece
501 ~ 1000 :	0.65 / Piece

PartNumber:: MAX4784EUE

Brand:: Maxim Integrated Products - Maxim | Pack: TSOP | D/C: 04+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Judy's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-24

From Other Seller

Part Number:MAX4784EUE
US $0.65 - 1.00
Quantity:

piece

Product Summary

The MAX4784EUE is a low on-resistance, low voltage, quad 2:1 analog multiplexer that operates from a single +1.6V to +4.2V supply. The MAX4784EUE has fast switching speeds (tON = 20ns, tOFF = 8ns), handle rail-to-rail analog signals, and consume less than 1μW of quiescent power. The applications of the MAX4784EUE include Power Routing, Battery-Powered Systems, Audio and Video Signal Routing, Low-Voltage Data-Acquisition Systems, Communications Circuits, PCMCIA Cards, Cellular Phones, Modems, Hard Drives.

Parametrics

MAX4784EUE absolute maximum ratings: (1)Voltages Referenced to GND V+, A_, EN: -0.3V to +4.6V; (2)COM_, NO_, NC_ (Note 1): -0.3V to (V+ + 0.3V); (3)Continuous Current COM_ , NO_, NC_: ±300mA; (4)Peak Current COM_, NO_, NC_ (pulsed at 1ms 10% duty cycle): ±500mA; (5)Continuous Power Dissipation (TA = +70℃); (6)16-Pin Thin QFN (derate 14.7mW/℃ above +70℃): 1176.5mW; (7)16-Pin TSSOP (derate 9.4mW/℃ above +70℃): 755mW; (8)Operating Temperature Range: -40℃ to +85℃; (9)Maximum Junction Temperature: +150℃; (10)Storage Temperature Range: -65℃ to +150℃; (11)Lead Temperature (soldering, 10s): +300℃.

Features

MAX4784EUE features: (1)Single-Supply Operation from 1.6V to 4.2V; (2)Low RON 0.7Ω (+2.7V Supply); (3)2Ω (+1.8V Supply); (4)0.1Ω RON Flatness (+2.7V Supply); (5)3mm x 3mm Thin QFN Package; (6)+1.8V CMOS Logic Compatible; (7)Fast Switching: tON = 20ns, tOFF = 8ns.
