MAX1237EUA

MAX1237EUA, 12-bit, multichannel analog-to-digital converter, MSOP, -0.3V to +6V, ±50mA, 362mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.65~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
101 ~ 500 :	0.80 / Piece
501 ~ 1000 :	0.65 / Piece

PartNumber:: MAX1237EUA

Brand:: Maxim Integrated Products - Maxim | Pack: MSOP | D/C: 99+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Judy's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-24

From Other Seller

Part Number:MAX1237EUA
US $0.65 - 1.00
Quantity:

piece

Product Summary

The MAX1237EUA is a low-power, 12-bit, multichannel analog-to-digital converter. It features internal track/hold (T/H), voltage reference, clock, and an I2C-compatible 2-wire serial interface. The MAX1237EUA operates from a single supply of 2.7V to 3.6V and requires only 670μA at the maximum sampling rate of 94.4ksps. Supply current falls below 230μA for sampling rates under 46ksps. AutoShutdown powers down the device between conversions, reducing supply current to less than 1μA at low throughput rates. The MAX1237EUA has four analog input channels each. The fully differential analog inputs are software configurable for unipolar or bipolar, and single-ended or differential operation. The applications of the MAX1237EUA include Hand-Held Portable Applications, Medical Instruments, Battery-Powered Test Equipment, Solar-Powered Remote Systems, Received-Signal-Strength Indicators, and System Supervision.

Parametrics

MAX1237EUA absolute maximum ratings: (1)VDD to GND: -0.3V to +6V; (2)AIN0–AIN11, REF to GND: -0.3V to the lower of (VDD + 0.3V) and 6V; (3)SDA, SCL to GND: -0.3V to +6V; (4)Maximum Current Into Any Pin: ±50mA; (5)Continuous Power Dissipation (TA = +70℃) 8-Pin μMAX (derate 4.5mW/℃ above +70℃): 362mW; (6)16-Pin QSOP (derate 8.3mW/℃ above +70℃): 666.7mW; (7)Operating Temperature Range: -40℃ to +85℃; (8)Junction Temperature: +150℃; (9)Storage Temperature Range: -60℃ to +150℃; (10)Lead Temperature (soldering, 10s): +300℃.

Features

MAX1237EUA features: (1)High-Speed I2C-Compatible Serial Interface: 400kHz Fast Mode, 1.7MHz High-Speed Mode; (2)Single-Supply: 2.7V to 3.6V; (3)Internal Reference: 2.048V; (4)External Reference: 1V to VDD; (5)Internal Clock; (6)4-Channel Single-Ended or 2-Channel Fully Differential (MAX1236/MAX1237); (7)12-Channel Single-Ended or 6-Channel Fully Differential (MAX1238/MAX1239); (8)Internal FIFO with Channel-Scan Mode; (9)Low Power; (10)Software-Configurable Unipolar/Bipolar; (11)Small Packages: 8-Pin μMAX(MAX1236/MAX1237), 16-Pin QSOP (MAX1238/MAX1239).
