Product Summary

The HD63B01X0D05F is a CMOS single-chip microcomputer unit which includes a CPU compatible with the HD630LV1, 4K bytes of ROM, 192 bytes of RAM, 53 parallel I/O pins, a serial communication interface and two timers on chip.

Parametrics

HD63B01X0D05F absolute maximum ratings: (1)Supply voltage: -0.3V to +7.0V; (2)Input voltage: -0.3V to VCC+0.3V; (3)Operating temperature: 0℃ to +70℃; (4)Storage temperature: -55℃ to +150℃.

Features

HD63B01X0D05F features: (1)Instruction set compatible with the HD6301V1; (2)Abundant On-chip functions; (3)Interrupts 3 external, 7 internal; (4)Operation mode; (5)Low power dissipation mode; (6)Wide range of Operation.

Diagrams

HD63B01X0D05F block diagram
