AT49LV161-70TI

AT49LV161-70TI, 2.65 to 3.3V, 16-megabit, Flash memory, TSOP, 40mA, 90ns

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~3.00

PartNumber:: AT49LV161-70TI

Brand:: ATMEL Corporation - ATMEL | Pack: SOP | D/C: 03+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Judy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-30

From Other Seller

Part Number:AT49LV161-70TI
US $1.00 - 3.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT49LV161-70TI is a 2.65- to 3.3-volt 16-megabit Flash memory organized as 1,048,576 words of 16 bits each or 2,097,152 bytes of 8 bits each. The x16 data appears on I/O0 - I/O15; the x8 data appears on I/O0 - I/O7. The memory is divided into 39 sectors for erase operations. The AT49LV161-70TI is offered in 48-lead TSOP and 48-ball CBGA packages. The device has CE and OE control signals to avoid any bus contention. The AT49LV161-70TI can be read or reprogrammed using a single 2.65V power supply, making it ideally suited for in-system programming.

Parametrics

AT49LV161-70TI absolute maximum ratings: (1)Temperature under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground:-0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on OE and VPP with Respect to Ground: -0.6V to +13.0V.

Features

AT49LV161-70TI features: (1)Single Voltage Read/Write Operation: 2.65V to 3.3V (BV), 3.0V to 3.6V (LV); (2)Access Time-70 ns; (3)Sector Erase Architecture; (4)Fast Word Program Time-20μs; (5)Fast Sector Erase Time-300 ms; (6)Dual-plane Organization, Permitting Concurrent Read while Program/Erase; (7)Erase Suspend Capability; (8)Low-power Operation; (9)Data Polling, Toggle Bit, Ready/Busy for End of Program Detection; (10)VPP Pin for Accelerated Program/Erase Operations; (11)RESET Input for Device Initialization; (12)Sector Lockdown Support; (13)TSOP and CBGA Package Options; (14)Top or Bottom Boot Block Configuration Available; (15)128-bit Protection Register.
