AD2S1000YSTX

AD2S1000YSTX, AC Vector Processor, 2KW, 60mW, +0.3V to -7.0V, QFP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.00~50.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $5.00~50.00

PartNumber:: AD2S1000YSTX

Brand:: Analog Devices - ADI | Pack: QFP | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Judy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-10

From Other Seller

Part Number:AD2S1000YSTX
US $5.00 - 50.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD2S1000YSTX is an AC Vector Processor. The AD2S1000YSTX performs the vector rotation of three-phase 120 degree or two-phase 90 degree sine and cosine signals by transferring these inputs into a new reference frame which is controlled by the digital input angle f. Two transforms are included in the AD2S1000YSTX. The first is the Clarke transform which computes the sine and cosine orthogonal components of a three-phase input. These signals represent real and imaginary components which then form the input to the Park transform. The Park transform relates the angle of the input signals to a reference frame controlled by the digital input port. The digital input port is a 12-bit parallel binary representation. The applications of the AD2S1000YSTX include AC Induction and DC Permanent, Magnet Motor Control, HVAC, Pump, Fan Control, Material Handling, Robotics, Spindle Drives, Gyroscopes, Dryers, Washing Machines, Electric Cars, Actuator, Three-Phase Power Measurement, Digital-to-Resolver & Synchro Conversion.

Parametrics

AD2S1000YSTX absolute maximum ratings: (1)VDD to AGND:–0.3 V to +7V dc; (2)VSS to AGND: +0.3 V to –7V dc; (3)AGND to DGND:±0.3 V dc; (4)Analog Input Voltage to AGND: VSS to VDD; (5)Digital Input Voltage to DGND:–0.3 V to VDD + 0.3 V dc; (6)Digital Output Voltage to DGND:–0.3 V to VDD + 0.3 V dc; (7)Analog Output Voltage to AGND: VSS–0.3 V to VDD + 0.3 V dc; (8)Analog Output Load Condition (PH/OP1, 2, 3, 4 Sinq, Cosq): 2 kW; (9)Power Dissipation: 60mW; (10)Operating Temperature Industrial (AP): –40℃ to +85℃; (11)Storage Temperature:–65℃ to +150℃; (12)Lead Temperature (Soldering, 10 sec): +300℃.

Features

AD2S1000YSTX features: (1)Complete Vector Coordinate Transformation on Silicon; (2)Mixed Signal Data Acquisition; (3)Three-Phase 120° and Orthogonal 90° Signal Transformation; (4)Three-Phase Balance Diagnostic–Homopolar Output.
