PEEL22CV10AP-15

PEEL22CV10AP-15, Programmable Electrically Erasable Logic device, CDIP, -0.5V to 7V, 25mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.65~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
101 ~ 500 :	0.80 / Piece
501 ~ 1000 :	0.65 / Piece

PartNumber:: PEEL22CV10AP-15

Brand:: Integrated Circuit Technology Corp - ICT | Pack: CDIP | D/C: 02+

Availability:: Supply Ability: 2/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Judy's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-25

From Other Seller

Part Number:PEEL22CV10AP-15
US $0.65 - 1.00
Quantity:

piece

Product Summary

The PEEL22CV10AP-15 is a Programmable Electrically Erasable Logic device providing an attractive alternative to ordinary PLDs. The PEEL22CV10AP-15 offers the performance, flexibility, ease of design and production practicality needed by logic designers today. The PEEL22CV10AP-15 is available in 24-pin DIP, SOIC, TSSOP and 28-pin PLCC packages, with speeds ranging from 7ns to 25ns and with power consumption as low as 30mA. EE-reprogrammability provides the convenience of instant reprogramming for development and a reusable production inventory, minimizing the impact of programming changes or errors. EE-reprogrammability also improves factory testability, thus ensuring the highest quality possible.

Parametrics

PEEL22CV10AP-15 absolute maximum ratings: (1)VCC Supply Voltage Relative to Ground: -0.5 to +7.0 V; (2)VI, VO Voltage Applied to Any Pin2 Relative to Ground1: -0.5 to VCC+0.6 V; (3)IO Output Current Per pin (IOL, IOH): ±25mA; (4)TST Storage Temperature: -65 to +150℃; (5)TLT Lead Temperature Soldering 10 second: +300℃.

Features

PEEL22CV10AP-15 features: (1) High Speed/Low Power; (2) Electrically Erasable Technology; (3) Development/Programmer Support; (4) Architectural Flexibility; (5) Application Versatility.
