Product Summary
The LM107J is a high-performance operational amplifier featuring very low input bias current and input offset voltage and current to improve the accuracy of high-impedance circuits using these devices. The high common-mode input voltage range and the absence of latch-up make these amplifiers ideal for voltage follower applications. The LM107J is short-circuit protected and the internal frequency compensation ensures stability without external components. The LM107J is characterized for operation over the full military temperature range of –55℃ to 125℃.
Parametrics
LM107J absolute maximum ratings: (1)Supply voltage, VCC + (see Note 1): 22V; (2)Supply voltage, VCC – (see Note 1):–22V; (3)Differential input voltage (see Note 2):±30V; (4)Input voltage (either input, see Notes 1 and 3):±15V; (5)Duration of output short circuit (see Note 4): unlimited; (6)Continuous total dissipation: See Dissipation Rating Table; (7)Operating free-air temperature range:–55 to 125℃; (8)Storage temperature range: –65 to 150℃; (9)Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: 300℃.
Features
LM107J features: (1)Low Input Currents; (2)No Frequency Compensation Required; (3)Low Input Offset Parameters; (4)Short-Circuit Protection; (5)No Latch-Up; (6)Wide Common-Mode and Differential Voltage Ranges.
Diagrams
 |
