HMC5843

HMC5843, surface mount multi-chip module, QFN, -0.3V to 5V, 2.5μA, 0.9mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.80~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
101 ~ 500 :	0.90 / Piece
501 ~ 1000 :	0.80 / Piece

PartNumber:: HMC5843

Brand:: Honeywell Solid State Electronics Center - Honeywell | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 200/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Judy's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-24

From Other Seller

Part Number:HMC5843
US $0.80 - 1.00
Quantity:

piece

Product Summary

The HMC5843 is a surface mount multi-chip module designed for low field magnetic sensing with a digital interface for applications such as low cost compassing and magnetometry. The HMC5843 includes our state of the art 1043 series magneto-resistive sensors plus Honeywell developed ASIC containing amplification, strap drivers, offset cancellation, 12-bit ADC and an I2C serial bus interface. The HMC5843 is in a 4.0 by 4.0 by 1.3mm surface mount leadless chip carrier (LCC). Applications for the HMC5843 include Consumer Electronics, Auto Navigation Systems, Personal Navigation Devices, and Magnetometers.

Parametrics

HMC5843 absolute maximum ratings: (1)Supply Voltage AVDD: -0.3 to 5Volts; (2)Supply Voltage DVDD: -0.3 to 2Volts; (3)Current Draw Sleep Mode (dual supply): 2.5μA; (4)Idle Mode (dual supply): 240μA; (5)Measurement Mode (10 Hz averaged): 0.8mA; (6)Sleep Mode (single supply): 110μA; (7)Idle Mode (single supply): 340μA; (8)Measurement Mode (10 Hz averaged): 0.9mA.
