Product Summary

The AT29C257-90JI is a 5-volt-only in-system Flash programmable and erasable read only memory (PEROM). Its 256K of memory is organized as 32,768 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS technology, the AT29C257-90JI offers access times to 70ns with power dissipation of just 275mW. When the AT29C257-90JI is deselected, the CMOS standby current is less than 300mA. The device endurance is such that any sector can typically be written to in excess of 10,000 times.

Parametrics

AT29C257-90JI absolute maximum ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on OE with Respect to Ground: -0.6V to +13.5V.

Features

AT29C257-90JI features: (1)Fast Read Access Time 70ns; (2)5-Volt-Only Reprogramming; (3)Page Program Operation Single Cycle Reprogram (Erase and Program) Internal Address and Data Latches for 64-Bytes; (4)Internal Program Control and Timer; (5)Hardware and Software Data Protection; (6)Fast Program Cycle Times Page (64-Byte) Program Time 10ms; (7)Chip Erase Time 10ms; (8)DATA Polling for End of Program Detection; (9)Low Power Dissipation: 50mA Active Current; (10)300mA CMOS Standby Current; (11)Typical Endurance ＞10,000 Cycles; (12)Single 5V ±10% Supply; (13)CMOS and TTL Compatible Inputs and Outputs; (14) Pin-Compatible with AT29C010A and AT29C512 for Easy System Upgrades.
