Product Summary
The AD9955KS is a direct digital synthesizer (DDS) featuring a 14-bit DAC operating up to 400 MSPS. The AD9955KS uses advanced DDS technology, coupled with an internal high speed, high performance DAC to form a digitally programmable, complete high frequency synthesizer capable of generating a frequency-agile analog output sinusoidal waveform at up to 200 MHz. The AD9951 is designed to provide fast frequency hopping and fine tuning resolution (32-bit frequency tuning word). The frequency tuning and control words are loaded into the AD9951 via a serial I/O port. The applications of the AD9955KS include Agile LO frequency synthesis, Programmable clock generators, Test and measurement equipment, Acousto-optic device drivers.
Parametrics
AD9955KS absolute maximum ratings: (1)Maximum Junction Temperature: 150℃; (2)DVDD_I/O (Pin 43): 4V; (3)AVDD, DVDD: 2V; (4)Digital Input Voltage (DVDD_I/O = 3.3 V): –0.7 V to +5.25 V; (5)Digital Input Voltage (DVDD_I/O = 1.8 V): –0.7 V to +2.2 V; (6)Digital Output Current: 5mA; (7)Storage Temperature:–65℃ to +150℃; (8)Operating Temperature: –40℃ to +105℃; (9)Lead Temperature (10 sec Soldering): 300℃; (10)θJA: 38℃/W; (11)θJC: 15℃/W.
Features
AD9955KS features: (1)400 MSPS internal clock speed; (2)Integrated 14-bit DAC; (3)32-bit tuning word; (4)Phase noise≤–120dBc/Hz @ 1 kHz offset (DAC output); (5)Excellent dynamic performance＞80 dB SFDR @ 160 MHz (±100 kHz offset) AOUT; (6)Serial I/O control; (7)1.8 V power supply; (8) Software and hardware controlled power-down; (9)48-lead TQFP/EP package; (10) Support for 5 V input levels on most digital inputs; (11) PLL REFCLK multiplier (4× to 20×); (12) Internal oscillator, can be driven by a single crystal; (13) Phase modulation capability; (14) Multichip synchronization.
Diagrams
 |
